Swan 45

Main

Appendages
Keel : fin with bulb
Category
Offshore racer-cruiser sailboat
Construction
GRP (glass reinforced polyester): Single skin bottom, sandwich sides and deck: fiberglass vinylester with carbon fiber reinforcements
Country
Finland
EC design category
A
First built hull
2001
Helm
Single helm wheel
Hull type
Monohull
Last built hull
2010
Model
Swan 45
Number of hulls built
0
Rudder
Single spade rudder
Sailboat builder
Nautor's Swan
Sailboat collection
ISAF
Sailboat designer
Frers Naval Architecture & Engineering
Standard public price ex. VAT (indicative only)
N/A €
Trailerable
No
Unsinkable
No

Dimensions

Ballast Type
Lead
Ballast type
Lead
Ballast weight
4310.0
Beam
3.91
Displacement
9850.0
Draft
2.8
Hull length
13.83
Light displacement (MLC)
8850.0
Max Draft
2.8
Maximum displacement (MLDC)
10850.0
Overall length
13.83
Waterline length
12.07

Sails

Downwind sail area
229.4
E
6.66
Est. Forestay Length
19.56
Fore area
50.77
Genoa area
54.7
I
18.7
J
5.4
Mainsail area
76.4
Mast configuration
Keel stepped mast
Number of levels of spreaders
2
P
18.66
Rigging type
Sloop Marconi 9/10
Rotating spars
No
Spars construction
Carbon fiber spars
Spreaders angle
Swept-back
Symmetric spinnaker area
153.0
Total area
112.78
Upwind sail area
131.1

Engine

Engine(s)
1 inboard engine
Engine(s) power
55.0
Engines amount
1
Fuel tank capacity
210.0
Fuel type
Diesel
Make
Perkins

Performance

Ballast ratio
49.0
Capsize Screening Formula
1.84
Comfort Ratio
27.14
Crew
950 kg max.
Critical hull speed
8.43
Displacement-length ratio (DLR)
143.0
Downwind sail area to displacement
53.62
HN (French rating)
35.0
Upwind sail area to displacement
30.64

Accomodation

Berth(s)
4
Berth(s) max
8
Boiler capacity
22.0
Cabin(s)
2
Cabin(s) max
3
Cockpit
Open aft cockpit
Freshwater tank capacity
320
Fridge/ice-box capacity
130.0
Holding tank capacity
60.0

Saloon

Fore_cabin

Aft_cabin

The Swan 45 is a high-performance sailing yacht designed by German Frers and built by Nautor's Swan, a Finnish yacht manufacturer. It was first introduced in 2001 and quickly gained popularity in the racing circuit due to its excellent sailing characteristics and sleek design.

Here are some key features and characteristics of the Swan 45:

1. Design: The Swan 45 features a modern and elegant design, with a sleek hull shape and a spacious cockpit. German Frers designed the yacht to be fast and competitive, while also providing comfort and ease of handling.

2. Construction: The yacht is built using advanced composite materials, including a carbon fiber hull and deck, which makes it lightweight and strong. This construction technique ensures excellent performance and durability.

3. Performance: The Swan 45 is known for its exceptional sailing performance. It has a powerful sail plan, including a large mainsail and a generous foretriangle, which allows for excellent upwind and downwind sailing. The yacht is also equipped with a deep keel and a balanced rudder, providing stability and responsiveness.

4. Racing: The Swan 45 is primarily designed for racing, and it has been successful in various regattas and offshore races around the world. It is known for its competitive nature and ability to perform well in a wide range of wind conditions.

5. Interior: While the Swan 45 is primarily focused on performance, it also offers a comfortable and well-appointed interior. It typically features a spacious saloon, a functional galley, and comfortable sleeping accommodations for a crew of up to eight people.

6. Class Association: The Swan 45 has a dedicated class association, which organizes racing events and promotes the class worldwide. This association ensures fair competition and provides a platform for owners to connect and share their experiences.

Overall, the Swan 45 is a highly regarded sailing yacht that combines performance, comfort, and elegance. It is a popular choice for sailors who are passionate about racing and seek a competitive and thrilling sailing experience.
